CVTF MULTI-TYPE is a universal fully synthetic automatic transmission fluid specifically designed for Continuously Variable Transmissions (CVT) gearbox type. Meets the demanding requirements of American, European, Japanese, Korean and other Asian car makers requiring a CVT fluid. Suitable for use in vehicles with either chain or belt pulleys CVT gearbox designs. Formulated with effective antishudder component to avoid vibrations and increase the driving comfort.
CVTF MULTI-TYPE protects gears that are of complex, compact and heavily loaded designs. Ensures good CVT performance in wide range of operating temperatures, enable accurate transfer of torque, prevents belt & chain slippage, making it the right choice of fluid.
Recommended for use in passenger cars, SUVs, CUVs, and other vehicles where CVT fluid is mandatory for use.
Applicable for use in CVT units installed in hybrid and electric vehicles.
Not compatible with CVT systems requiring high torque and low vis CVT fluids.
WARRANTY
CVTF MULTI-TYPE meets or exceeds the OEM’s warranty requirements where a conventional CVT fluid is required. TOTACHI ® guarantees full compliance on the written specifications indicated on product labels.
Durable transmission life
Good air release characteristics to maintain effective lubrication even in severe driving conditions. Ensures gear wear protection to prolong the life of the transmission.
Outstanding fuel efficiency
Well balanced friction properties for an improved power transfer performance of a rigorous requirement of a CVT gearbox design.
Noiseless gear shifts
With carefully selected components to effectively reduce noise during gear shifts for quitter driving and ultimate driving comfort.
Optimum drain intervals
Shear stable to prevent oil film breakdown for a guaranteed performance and maximum fluid life in a sophisticated CVT technology during the oil life service.
Specification
CVTF-EX1
PUNCH CVTF-EX1
HYUNDAI SP-CVT 1
KIA SP-CVT 1
TOYOTA TC
TOYOTA FE
NISSAN CVT NS-2
MITSUBISHI CVTF-J1, CVTF-J4
SUZUKI CVT 3320
Technical Property | Method | Result |
---|---|---|
SAE viscosity grade | SAE J300 | 5W-30 |
Density at 15°C | ASTM D-4052 | 0,8485 |
Flash point, °C | ASTM D-92 | 218 |
TBN (mg KOH/g) | ASTM D-2896 | 8,00 |
Pour point, °C | ASTM D-97 | -39 |
Colour | ASTM D-1500 | <3,0 |
Viscosity index | ASTM D-2270 | 170 |
Kinematic viscosity at 40°C (cSt) | ASTM D-445 | 62,00 |
Kinematic viscosity at 100°C (cSt) | ASTM D-445 | 10,95 |
Due to continual product research and development, the information contained herein is subject to change without notification.
